Supports 66,000+ IC devices from 263 manufacturers and continuing
Programs devices with Vcc as low as 1.2V.
Ultra fast programming speed: Programs and verifies 64 Mb NOR FLASH memory in 11.3 seconds.
Built with 144 universal pin-drivers for support of today’s most complex devices. Universal and device independent socket adapters are available for various packages up to 144 pins.
The programmer operates in either PC hosted mode or stand-alone mode.
Under PC hosted mode, a PC controls the programmer via a high-speed USB2.0 connection to program a chip.
Under stand-alone mode, the user controls the programmer via
20-characters, 4-line LCD display with 6-KEY
A CF (compact flash) card stores the project files.
ISP/ICP programming capability through optional ISP/ICP adapter.
In stand-alone mode, the user can operate multiple units to construct a concurrent multiprogramming system.
Over-current and over-voltage protection for safety of the chip and programmer hardware.
Compatible with Windows 7 & Vista & XP 32/64 bit
Only IC manufacturer approved programming algorithms provide high reliability.
Vcc verification at (+5%~-5%) and (10%~-10%) enhances programming reliability.
Includes the following advanced and powerful software functions:
Chip operation starts immediately upon proper chip insertion in Production Mode.
Project function simplifies processes such as device selection, file loading, device configuration setting, program option, and batch file setting into one step.
Password protection provides security for project files and production volume control.
Batch command combines device operations like program, verify, security into a single command at any sequence.
Serial number generators are available as standard or customer-specific functions.
Log file provides production quality tracking.
CE and RoHSCompliant
Devices Supported:
EPROM, Paged EPROM, Parallel and Serial EEPROM, FPGA Configuration PROM, FLASH memory (NOR), BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU, Standard Logic
Package: DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP, SON, EBGA, FBGA, VFBGA, uBGA, CSP, SCSP
PC interface: USB2.0 (High speed)
Stand-alone memory: Compact FLASH Card
Power supply: AC Adapter: Input AC 100V- 240V; Output: 12V/1.5A
Main unit: Dimensions 148(L) * 216(W) * 94(h) mm; Weight 3.5 lbs (1.6 Kg)
Package: Dimensions 301(L) * 252(W) * 145(H) mm; Weight 6.2 lbs
