Factory will not produce it. pls order beeprog
Features:
- Supports
<>device_count("sp580u");
30,647+ devices from
<>manufacturer_count("sp580u");
171+ IC manufacturers.
- High speed programming. 32Mb FLASH 13.5 sec (Program+verify)
- ISP (In-System Programmable) devices supported
- USB Interfaced
- 430+ socket adapters including 150+ FBGA package types supported
- CE and ROHS Compliant
- Very low-cost, high performance, and very compact
- Highest value in the industry $0.035/device supported
- Speed comparison:
| Type |
Program (sec) |
Verify (sec) |
Program+verify (sec) |
Memory Size (ea) |
| 28F320W18 |
9 |
4.5 |
13.5 |
32Mb FLASH |
| 28F640W30 |
18 |
9 |
27 |
64Mb FLASH |
| AM29DL640E |
38.3 |
10.6 |
48.9 |
64Mb FLASH |
| MB84VD21182DA |
9.6 |
2.9 |
12.5 |
16Mb FLASH |
| MB84VD23280FA |
38.3 |
10.6 |
48.9 |
64Mb FLASH |
| LRS1381 |
13.3 |
4.6 |
19.9 |
32Mb FLASH |
| M36W432TG |
11.8 |
4.6 |
16.4 |
32Mb FLASH |
| MBM29DL323TE |
17.5 |
5.5 |
23.3 |
32Mb FLASH |
| AT89C55WD |
2.1 |
1 |
3.1 |
20KB MCU |
| P89C51RD2B |
4.6 |
0.9 |
5.5 |
64KB MCU |
Specifications:
- Device Supported:
EPROM, Paged EPROM, Parallel and Serial EEPROM, FPGA Configuration Serial PROM, FLASH Memory (NOR and NAND), NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU, Standard Logic.
- Socket Adapters Supported:
DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, VQFP, TSOP, TSOPII, SOP, P SOP, TSSOP, SON, EBGA, FBGA, VFBGA, µBGA, CSP, SCSP, etc.
- PC Interface: USB
- Optional Accessories: Package Adapter
