S100 Features:

* Support More than 300 IC manufacturer, More than 80000 pcs devices.

* Support devices with Vcc Voltages as low as 1.2V

* Extremely fast speed. 64 Mb NOR FLASH memory in 12 seconds and 1Gb NAND in 110 seconds.

* Built with 144 universal pin-drivers. Universal adaptors are available for varies packages up to 144 pins. New device support will be easier.

* The programmer is controlled by a PC via USB2.0 (high speed) to program a chip.

* ISP/ICP programming capability available via ISP/ICP adaptor.

* Only IC manufacturer approved programming algorithms are used for high reliability. (+5%~-5%) and (10%~-10%) Vcc verification enhances programming reliability.

* Over-current and over-voltage protection for safety of the chip and programmer hardware.

* Windows XP/Vista/Win7 compatibility

Hardware & Electrical Specifications:

Supported devices: EPROM, Paged EPROM, Parallel and Serial EEPROM, FPGA Configuration PROM, FLASH memory (NOR & NAND)n, BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU. .

Packages supported: DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP, SON, EBGA, FBGA, VFBGA, uBGA, CSP, SCSP, ...

PC interface: USB2.0

Power:

Power source: 100~240 V  AC 50~60 Hz

Power consumption: ~0.5 A

Dimension(W*D*H): 134mm*188mm*65mm
